MRBooleanOperation.h File Reference

#include <MRCMisc/common.h>
#include <MRCMisc/exports.h>
#include <stdbool.h>
#include <stddef.h>

Go to the source code of this file.

Typedefs
typedef struct MR_AffineXf3f	MR_AffineXf3f
typedef struct MR_EdgeBitSet	MR_EdgeBitSet
typedef struct MR_FaceBitSet	MR_FaceBitSet
typedef struct MR_FaceMap	MR_FaceMap
typedef struct MR_Mesh	MR_Mesh
typedef struct MR_UndirectedEdgeBitSet	MR_UndirectedEdgeBitSet
typedef struct MR_VertBitSet	MR_VertBitSet
typedef struct MR_VertMap	MR_VertMap
typedef struct MR_WholeEdgeMap	MR_WholeEdgeMap
typedef struct MR_expected_MR_Mesh_std_string	MR_expected_MR_Mesh_std_string
typedef struct MR_std_array_MR_BooleanResultMapper_Maps_2	MR_std_array_MR_BooleanResultMapper_Maps_2
typedef struct MR_std_vector_std_vector_MR_EdgeId	MR_std_vector_std_vector_MR_EdgeId
typedef enum MR_BooleanOperation	MR_BooleanOperation
typedef struct MR_BooleanResultMapper	MR_BooleanResultMapper
	Generated from class MR::BooleanResultMapper.
typedef enum MR_BooleanResultMapper_MapObject	MR_BooleanResultMapper_MapObject
	Input object index enum.
typedef struct MR_BooleanResultMapper_Maps	MR_BooleanResultMapper_Maps
	Generated from class MR::BooleanResultMapper::Maps.
typedef struct MR_BooleanInternalParameters	MR_BooleanInternalParameters

Enumerations
enum	MR_BooleanOperation {   MR_BooleanOperation_InsideA = 0 , MR_BooleanOperation_InsideB = 1 , MR_BooleanOperation_OutsideA = 2 , MR_BooleanOperation_OutsideB = 3 ,   MR_BooleanOperation_Union = 4 , MR_BooleanOperation_Intersection = 5 , MR_BooleanOperation_DifferenceBA = 6 , MR_BooleanOperation_DifferenceAB = 7 ,   MR_BooleanOperation_Count = 8 }
enum	MR_BooleanResultMapper_MapObject { MR_BooleanResultMapper_MapObject_A = 0 , MR_BooleanResultMapper_MapObject_B = 1 , MR_BooleanResultMapper_MapObject_Count = 2 }
	Input object index enum. More...

Functions
MRC_API const MR_std_array_MR_BooleanResultMapper_Maps_2 *	MR_BooleanResultMapper_Get_maps (const MR_BooleanResultMapper *_this)
MRC_API void	MR_BooleanResultMapper_Set_maps (MR_BooleanResultMapper *_this, MR_PassBy value_pass_by, MR_std_array_MR_BooleanResultMapper_Maps_2 *value)
MRC_API MR_std_array_MR_BooleanResultMapper_Maps_2 *	MR_BooleanResultMapper_GetMutable_maps (MR_BooleanResultMapper *_this)
MRC_API MR_BooleanResultMapper *	MR_BooleanResultMapper_DefaultConstruct (void)
MRC_API MR_BooleanResultMapper *	MR_BooleanResultMapper_DefaultConstructArray (size_t num_elems)
MRC_API const MR_BooleanResultMapper *	MR_BooleanResultMapper_OffsetPtr (const MR_BooleanResultMapper *ptr, ptrdiff_t i)
	Offsets a pointer to an array element by i positions (not bytes). Use only if you're certain that the pointer points to an array element.
MRC_API MR_BooleanResultMapper *	MR_BooleanResultMapper_OffsetMutablePtr (MR_BooleanResultMapper *ptr, ptrdiff_t i)
	Offsets a pointer to an array element by i positions (not bytes). Use only if you're certain that the pointer points to an array element.
MRC_API MR_BooleanResultMapper *	MR_BooleanResultMapper_ConstructFromAnother (MR_PassBy _other_pass_by, MR_BooleanResultMapper *_other)
MRC_API void	MR_BooleanResultMapper_Destroy (const MR_BooleanResultMapper *_this)
	Destroys a heap-allocated instance of MR_BooleanResultMapper. Does nothing if the pointer is null.
MRC_API void	MR_BooleanResultMapper_DestroyArray (const MR_BooleanResultMapper *_this)
	Destroys a heap-allocated array of MR_BooleanResultMapper. Does nothing if the pointer is null.
MRC_API MR_BooleanResultMapper *	MR_BooleanResultMapper_AssignFromAnother (MR_BooleanResultMapper *_this, MR_PassBy _other_pass_by, MR_BooleanResultMapper *_other)
MRC_API MR_FaceBitSet *	MR_BooleanResultMapper_map_MR_FaceBitSet (const MR_BooleanResultMapper *_this, const MR_FaceBitSet *oldBS, MR_BooleanResultMapper_MapObject obj)
MRC_API MR_VertBitSet *	MR_BooleanResultMapper_map_MR_VertBitSet (const MR_BooleanResultMapper *_this, const MR_VertBitSet *oldBS, MR_BooleanResultMapper_MapObject obj)
MRC_API MR_EdgeBitSet *	MR_BooleanResultMapper_map_MR_EdgeBitSet (const MR_BooleanResultMapper *_this, const MR_EdgeBitSet *oldBS, MR_BooleanResultMapper_MapObject obj)
MRC_API MR_UndirectedEdgeBitSet *	MR_BooleanResultMapper_map_MR_UndirectedEdgeBitSet (const MR_BooleanResultMapper *_this, const MR_UndirectedEdgeBitSet *oldBS, MR_BooleanResultMapper_MapObject obj)
MRC_API MR_FaceBitSet *	MR_BooleanResultMapper_newFaces (const MR_BooleanResultMapper *_this)
MRC_API MR_FaceBitSet *	MR_BooleanResultMapper_filteredOldFaceBitSet (MR_BooleanResultMapper *_this, const MR_FaceBitSet *oldBS, MR_BooleanResultMapper_MapObject obj)
MRC_API const MR_BooleanResultMapper_Maps *	MR_BooleanResultMapper_getMaps (const MR_BooleanResultMapper *_this, MR_BooleanResultMapper_MapObject index)
MRC_API const MR_FaceMap *	MR_BooleanResultMapper_Maps_Get_cut2origin (const MR_BooleanResultMapper_Maps *_this)
MRC_API void	MR_BooleanResultMapper_Maps_Set_cut2origin (MR_BooleanResultMapper_Maps *_this, MR_PassBy value_pass_by, MR_FaceMap *value)
MRC_API MR_FaceMap *	MR_BooleanResultMapper_Maps_GetMutable_cut2origin (MR_BooleanResultMapper_Maps *_this)
MRC_API const MR_FaceMap *	MR_BooleanResultMapper_Maps_Get_cut2newFaces (const MR_BooleanResultMapper_Maps *_this)
MRC_API void	MR_BooleanResultMapper_Maps_Set_cut2newFaces (MR_BooleanResultMapper_Maps *_this, MR_PassBy value_pass_by, MR_FaceMap *value)
MRC_API MR_FaceMap *	MR_BooleanResultMapper_Maps_GetMutable_cut2newFaces (MR_BooleanResultMapper_Maps *_this)
MRC_API const MR_WholeEdgeMap *	MR_BooleanResultMapper_Maps_Get_old2newEdges (const MR_BooleanResultMapper_Maps *_this)
MRC_API void	MR_BooleanResultMapper_Maps_Set_old2newEdges (MR_BooleanResultMapper_Maps *_this, MR_PassBy value_pass_by, MR_WholeEdgeMap *value)
MRC_API MR_WholeEdgeMap *	MR_BooleanResultMapper_Maps_GetMutable_old2newEdges (MR_BooleanResultMapper_Maps *_this)
MRC_API const MR_VertMap *	MR_BooleanResultMapper_Maps_Get_old2newVerts (const MR_BooleanResultMapper_Maps *_this)
MRC_API void	MR_BooleanResultMapper_Maps_Set_old2newVerts (MR_BooleanResultMapper_Maps *_this, MR_PassBy value_pass_by, MR_VertMap *value)
MRC_API MR_VertMap *	MR_BooleanResultMapper_Maps_GetMutable_old2newVerts (MR_BooleanResultMapper_Maps *_this)
MRC_API const bool *	MR_BooleanResultMapper_Maps_Get_identity (const MR_BooleanResultMapper_Maps *_this)
MRC_API void	MR_BooleanResultMapper_Maps_Set_identity (MR_BooleanResultMapper_Maps *_this, bool value)
MRC_API bool *	MR_BooleanResultMapper_Maps_GetMutable_identity (MR_BooleanResultMapper_Maps *_this)
MRC_API MR_BooleanResultMapper_Maps *	MR_BooleanResultMapper_Maps_DefaultConstruct (void)
MRC_API MR_BooleanResultMapper_Maps *	MR_BooleanResultMapper_Maps_DefaultConstructArray (size_t num_elems)
MRC_API MR_BooleanResultMapper_Maps *	MR_BooleanResultMapper_Maps_ConstructFrom (MR_PassBy cut2origin_pass_by, MR_FaceMap *cut2origin, MR_PassBy cut2newFaces_pass_by, MR_FaceMap *cut2newFaces, MR_PassBy old2newEdges_pass_by, MR_WholeEdgeMap *old2newEdges, MR_PassBy old2newVerts_pass_by, MR_VertMap *old2newVerts, bool identity)
MRC_API const MR_BooleanResultMapper_Maps *	MR_BooleanResultMapper_Maps_OffsetPtr (const MR_BooleanResultMapper_Maps *ptr, ptrdiff_t i)
	Offsets a pointer to an array element by i positions (not bytes). Use only if you're certain that the pointer points to an array element.
MRC_API MR_BooleanResultMapper_Maps *	MR_BooleanResultMapper_Maps_OffsetMutablePtr (MR_BooleanResultMapper_Maps *ptr, ptrdiff_t i)
	Offsets a pointer to an array element by i positions (not bytes). Use only if you're certain that the pointer points to an array element.
MRC_API MR_BooleanResultMapper_Maps *	MR_BooleanResultMapper_Maps_ConstructFromAnother (MR_PassBy _other_pass_by, MR_BooleanResultMapper_Maps *_other)
MRC_API void	MR_BooleanResultMapper_Maps_Destroy (const MR_BooleanResultMapper_Maps *_this)
	Destroys a heap-allocated instance of MR_BooleanResultMapper_Maps. Does nothing if the pointer is null.
MRC_API void	MR_BooleanResultMapper_Maps_DestroyArray (const MR_BooleanResultMapper_Maps *_this)
	Destroys a heap-allocated array of MR_BooleanResultMapper_Maps. Does nothing if the pointer is null.
MRC_API MR_BooleanResultMapper_Maps *	MR_BooleanResultMapper_Maps_AssignFromAnother (MR_BooleanResultMapper_Maps *_this, MR_PassBy _other_pass_by, MR_BooleanResultMapper_Maps *_other)
MRC_API const MR_Mesh *const *	MR_BooleanInternalParameters_Get_originalMeshA (const MR_BooleanInternalParameters *_this)
MRC_API void	MR_BooleanInternalParameters_Set_originalMeshA (MR_BooleanInternalParameters *_this, const MR_Mesh *value)
MRC_API const MR_Mesh **	MR_BooleanInternalParameters_GetMutable_originalMeshA (MR_BooleanInternalParameters *_this)
MRC_API const MR_Mesh *const *	MR_BooleanInternalParameters_Get_originalMeshB (const MR_BooleanInternalParameters *_this)
MRC_API void	MR_BooleanInternalParameters_Set_originalMeshB (MR_BooleanInternalParameters *_this, const MR_Mesh *value)
MRC_API const MR_Mesh **	MR_BooleanInternalParameters_GetMutable_originalMeshB (MR_BooleanInternalParameters *_this)
MRC_API MR_std_vector_std_vector_MR_EdgeId *const *	MR_BooleanInternalParameters_Get_optionalOutCut (const MR_BooleanInternalParameters *_this)
MRC_API void	MR_BooleanInternalParameters_Set_optionalOutCut (MR_BooleanInternalParameters *_this, MR_std_vector_std_vector_MR_EdgeId *value)
MRC_API MR_std_vector_std_vector_MR_EdgeId **	MR_BooleanInternalParameters_GetMutable_optionalOutCut (MR_BooleanInternalParameters *_this)
MRC_API MR_BooleanInternalParameters *	MR_BooleanInternalParameters_DefaultConstruct (void)
MRC_API MR_BooleanInternalParameters *	MR_BooleanInternalParameters_DefaultConstructArray (size_t num_elems)
MRC_API MR_BooleanInternalParameters *	MR_BooleanInternalParameters_ConstructFrom (const MR_Mesh *originalMeshA, const MR_Mesh *originalMeshB, MR_std_vector_std_vector_MR_EdgeId *optionalOutCut)
MRC_API const MR_BooleanInternalParameters *	MR_BooleanInternalParameters_OffsetPtr (const MR_BooleanInternalParameters *ptr, ptrdiff_t i)
	Offsets a pointer to an array element by i positions (not bytes). Use only if you're certain that the pointer points to an array element.
MRC_API MR_BooleanInternalParameters *	MR_BooleanInternalParameters_OffsetMutablePtr (MR_BooleanInternalParameters *ptr, ptrdiff_t i)
	Offsets a pointer to an array element by i positions (not bytes). Use only if you're certain that the pointer points to an array element.
MRC_API MR_BooleanInternalParameters *	MR_BooleanInternalParameters_ConstructFromAnother (const MR_BooleanInternalParameters *_other)
MRC_API void	MR_BooleanInternalParameters_Destroy (const MR_BooleanInternalParameters *_this)
	Destroys a heap-allocated instance of MR_BooleanInternalParameters. Does nothing if the pointer is null.
MRC_API void	MR_BooleanInternalParameters_DestroyArray (const MR_BooleanInternalParameters *_this)
	Destroys a heap-allocated array of MR_BooleanInternalParameters. Does nothing if the pointer is null.
MRC_API MR_BooleanInternalParameters *	MR_BooleanInternalParameters_AssignFromAnother (MR_BooleanInternalParameters *_this, const MR_BooleanInternalParameters *_other)
MRC_API MR_expected_MR_Mesh_std_string *	MR_doBooleanOperation (MR_Mesh *meshACut, MR_Mesh *meshBCut, const MR_std_vector_std_vector_MR_EdgeId *cutEdgesA, const MR_std_vector_std_vector_MR_EdgeId *cutEdgesB, MR_BooleanOperation operation, const MR_AffineXf3f *rigidB2A, MR_BooleanResultMapper *mapper, const bool *mergeAllNonIntersectingComponents, const MR_BooleanInternalParameters *intParams)

Typedef Documentation

MR_AffineXf3f

typedef struct MR_AffineXf3f MR_AffineXf3f

MR_BooleanInternalParameters

typedef struct MR_BooleanInternalParameters MR_BooleanInternalParameters

Parameters will be useful if specified Generated from class MR::BooleanInternalParameters.

MR_BooleanOperation

typedef enum MR_BooleanOperation MR_BooleanOperation

Enum class of available CSG operations

Two separate meshes

See also

MR::boolean

MR_BooleanResultMapper

typedef struct MR_BooleanResultMapper MR_BooleanResultMapper

Generated from class MR::BooleanResultMapper.

MR_BooleanResultMapper_MapObject

typedef enum MR_BooleanResultMapper_MapObject MR_BooleanResultMapper_MapObject

Input object index enum.

MR_BooleanResultMapper_Maps

typedef struct MR_BooleanResultMapper_Maps MR_BooleanResultMapper_Maps

Generated from class MR::BooleanResultMapper::Maps.

MR_EdgeBitSet

typedef struct MR_EdgeBitSet MR_EdgeBitSet

MR_expected_MR_Mesh_std_string

typedef struct MR_expected_MR_Mesh_std_string MR_expected_MR_Mesh_std_string

MR_FaceBitSet

typedef struct MR_FaceBitSet MR_FaceBitSet

MR_FaceMap

typedef struct MR_FaceMap MR_FaceMap

MR_Mesh

typedef struct MR_Mesh MR_Mesh

MR_std_array_MR_BooleanResultMapper_Maps_2

typedef struct MR_std_array_MR_BooleanResultMapper_Maps_2 MR_std_array_MR_BooleanResultMapper_Maps_2

MR_std_vector_std_vector_MR_EdgeId

typedef struct MR_std_vector_std_vector_MR_EdgeId MR_std_vector_std_vector_MR_EdgeId

MR_UndirectedEdgeBitSet

typedef struct MR_UndirectedEdgeBitSet MR_UndirectedEdgeBitSet

MR_VertBitSet

typedef struct MR_VertBitSet MR_VertBitSet

MR_VertMap

typedef struct MR_VertMap MR_VertMap

MR_WholeEdgeMap

typedef struct MR_WholeEdgeMap MR_WholeEdgeMap

Enumeration Type Documentation

MR_BooleanOperation

enum MR_BooleanOperation

Enum class of available CSG operations

Two separate meshes

See also

MR::boolean

Enumerator
MR_BooleanOperation_InsideA	Part of mesh A that is inside of mesh B Inside A
MR_BooleanOperation_InsideB	Part of mesh B that is inside of mesh A Inside B
MR_BooleanOperation_OutsideA	Part of mesh A that is outside of mesh B Outside A
MR_BooleanOperation_OutsideB	Part of mesh B that is outside of mesh A Outside B
MR_BooleanOperation_Union	Union surface of two meshes (outside parts) Union
MR_BooleanOperation_Intersection	Intersection surface of two meshes (inside parts) Intersection
MR_BooleanOperation_DifferenceBA	Surface of mesh B - surface of mesh A (outside B - inside A) Difference B-A
MR_BooleanOperation_DifferenceAB	not a valid operation Surface of mesh A - surface of mesh B (outside A - inside B) Difference A-B
MR_BooleanOperation_Count

MR_BooleanResultMapper_MapObject

enum MR_BooleanResultMapper_MapObject

Input object index enum.

Enumerator
MR_BooleanResultMapper_MapObject_A
MR_BooleanResultMapper_MapObject_B
MR_BooleanResultMapper_MapObject_Count

Function Documentation

MR_BooleanInternalParameters_AssignFromAnother()

MRC_API MR_BooleanInternalParameters * MR_BooleanInternalParameters_AssignFromAnother	(	MR_BooleanInternalParameters *	_this,
		const MR_BooleanInternalParameters *	_other )

Generated from a method of class MR::BooleanInternalParameters named operator=. Parameter _this can not be null. It is a single object. Parameter _other can not be null. It is a single object. The returned pointer will never be null. It is non-owning, do NOT destroy it.

MR_BooleanInternalParameters_ConstructFrom()

MRC_API MR_BooleanInternalParameters * MR_BooleanInternalParameters_ConstructFrom	(	const MR_Mesh *	originalMeshA,
		const MR_Mesh *	originalMeshB,
		MR_std_vector_std_vector_MR_EdgeId *	optionalOutCut )

Constructs MR::BooleanInternalParameters elementwise. Never returns null. Returns an instance allocated on the heap! Must call MR_BooleanInternalParameters_Destroy() to free it when you're done using it.

MR_BooleanInternalParameters_ConstructFromAnother()

MRC_API MR_BooleanInternalParameters * MR_BooleanInternalParameters_ConstructFromAnother

(

const MR_BooleanInternalParameters *

_other

)

Generated from a constructor of class MR::BooleanInternalParameters. Parameter _other can not be null. It is a single object. Never returns null. Returns an instance allocated on the heap! Must call MR_BooleanInternalParameters_Destroy() to free it when you're done using it.

MR_BooleanInternalParameters_DefaultConstruct()

MRC_API MR_BooleanInternalParameters * MR_BooleanInternalParameters_DefaultConstruct

(

void

)

Constructs an empty (default-constructed) instance. Never returns null. Returns an instance allocated on the heap! Must call MR_BooleanInternalParameters_Destroy() to free it when you're done using it.

MR_BooleanInternalParameters_DefaultConstructArray()

MRC_API MR_BooleanInternalParameters * MR_BooleanInternalParameters_DefaultConstructArray

(

size_t

num_elems

)

Constructs an array of empty (default-constructed) instances, of the specified size. Will never return null. The array must be destroyed using MR_BooleanInternalParameters_DestroyArray(). Use MR_BooleanInternalParameters_OffsetMutablePtr() and MR_BooleanInternalParameters_OffsetPtr() to access the array elements.

MR_BooleanInternalParameters_Destroy()

MRC_API void MR_BooleanInternalParameters_Destroy

(

const MR_BooleanInternalParameters *

_this

)

Destroys a heap-allocated instance of MR_BooleanInternalParameters. Does nothing if the pointer is null.

MR_BooleanInternalParameters_DestroyArray()

MRC_API void MR_BooleanInternalParameters_DestroyArray

(

const MR_BooleanInternalParameters *

_this

)

Destroys a heap-allocated array of MR_BooleanInternalParameters. Does nothing if the pointer is null.

MR_BooleanInternalParameters_Get_optionalOutCut()

MRC_API MR_std_vector_std_vector_MR_EdgeId *const * MR_BooleanInternalParameters_Get_optionalOutCut

(

const MR_BooleanInternalParameters *

_this

)

Optional output cut edges of booleaned meshes Returns a pointer to a member variable of class MR::BooleanInternalParameters named optionalOutCut. Parameter _this can not be null. It is a single object. The returned pointer will never be null. It is non-owning, do NOT destroy it.

MR_BooleanInternalParameters_Get_originalMeshA()

MRC_API const MR_Mesh *const * MR_BooleanInternalParameters_Get_originalMeshA

(

const MR_BooleanInternalParameters *

_this

)

Instance of original mesh with tree for better speed Returns a pointer to a member variable of class MR::BooleanInternalParameters named originalMeshA. Parameter _this can not be null. It is a single object. The returned pointer will never be null. It is non-owning, do NOT destroy it.

MR_BooleanInternalParameters_Get_originalMeshB()

MRC_API const MR_Mesh *const * MR_BooleanInternalParameters_Get_originalMeshB

(

const MR_BooleanInternalParameters *

_this

)

Instance of original mesh with tree for better speed Returns a pointer to a member variable of class MR::BooleanInternalParameters named originalMeshB. Parameter _this can not be null. It is a single object. The returned pointer will never be null. It is non-owning, do NOT destroy it.

MR_BooleanInternalParameters_GetMutable_optionalOutCut()

MRC_API MR_std_vector_std_vector_MR_EdgeId ** MR_BooleanInternalParameters_GetMutable_optionalOutCut

(

MR_BooleanInternalParameters *

_this

)

Optional output cut edges of booleaned meshes Returns a mutable pointer to a member variable of class MR::BooleanInternalParameters named optionalOutCut. Parameter _this can not be null. It is a single object. The returned pointer will never be null. It is non-owning, do NOT destroy it.

MR_BooleanInternalParameters_GetMutable_originalMeshA()

MRC_API const MR_Mesh ** MR_BooleanInternalParameters_GetMutable_originalMeshA

(

MR_BooleanInternalParameters *

_this

)

Instance of original mesh with tree for better speed Returns a mutable pointer to a member variable of class MR::BooleanInternalParameters named originalMeshA. Parameter _this can not be null. It is a single object. The returned pointer will never be null. It is non-owning, do NOT destroy it.

MR_BooleanInternalParameters_GetMutable_originalMeshB()

MRC_API const MR_Mesh ** MR_BooleanInternalParameters_GetMutable_originalMeshB

(

MR_BooleanInternalParameters *

_this

)

Instance of original mesh with tree for better speed Returns a mutable pointer to a member variable of class MR::BooleanInternalParameters named originalMeshB. Parameter _this can not be null. It is a single object. The returned pointer will never be null. It is non-owning, do NOT destroy it.

MR_BooleanInternalParameters_OffsetMutablePtr()

MRC_API MR_BooleanInternalParameters * MR_BooleanInternalParameters_OffsetMutablePtr	(	MR_BooleanInternalParameters *	ptr,
		ptrdiff_t	i )

Offsets a pointer to an array element by i positions (not bytes). Use only if you're certain that the pointer points to an array element.

MR_BooleanInternalParameters_OffsetPtr()

MRC_API const MR_BooleanInternalParameters * MR_BooleanInternalParameters_OffsetPtr	(	const MR_BooleanInternalParameters *	ptr,
		ptrdiff_t	i )

Offsets a pointer to an array element by i positions (not bytes). Use only if you're certain that the pointer points to an array element.

MR_BooleanInternalParameters_Set_optionalOutCut()

MRC_API void MR_BooleanInternalParameters_Set_optionalOutCut	(	MR_BooleanInternalParameters *	_this,
		MR_std_vector_std_vector_MR_EdgeId *	value )

Optional output cut edges of booleaned meshes Modifies a member variable of class MR::BooleanInternalParameters named optionalOutCut. Parameter _this can not be null. It is a single object.

MR_BooleanInternalParameters_Set_originalMeshA()

MRC_API void MR_BooleanInternalParameters_Set_originalMeshA	(	MR_BooleanInternalParameters *	_this,
		const MR_Mesh *	value )

Instance of original mesh with tree for better speed Modifies a member variable of class MR::BooleanInternalParameters named originalMeshA. Parameter _this can not be null. It is a single object.

MR_BooleanInternalParameters_Set_originalMeshB()

MRC_API void MR_BooleanInternalParameters_Set_originalMeshB	(	MR_BooleanInternalParameters *	_this,
		const MR_Mesh *	value )

Instance of original mesh with tree for better speed Modifies a member variable of class MR::BooleanInternalParameters named originalMeshB. Parameter _this can not be null. It is a single object.

MR_BooleanResultMapper_AssignFromAnother()

MRC_API MR_BooleanResultMapper * MR_BooleanResultMapper_AssignFromAnother	(	MR_BooleanResultMapper *	_this,
		MR_PassBy	_other_pass_by,
		MR_BooleanResultMapper *	_other )

Generated from a method of class MR::BooleanResultMapper named operator=. Parameter _this can not be null. It is a single object. The returned pointer will never be null. It is non-owning, do NOT destroy it.

MR_BooleanResultMapper_ConstructFromAnother()

MRC_API MR_BooleanResultMapper * MR_BooleanResultMapper_ConstructFromAnother	(	MR_PassBy	_other_pass_by,
		MR_BooleanResultMapper *	_other )

Generated from a constructor of class MR::BooleanResultMapper. Never returns null. Returns an instance allocated on the heap! Must call MR_BooleanResultMapper_Destroy() to free it when you're done using it.

MR_BooleanResultMapper_DefaultConstruct()

MRC_API MR_BooleanResultMapper * MR_BooleanResultMapper_DefaultConstruct

(

void

)

Constructs an empty (default-constructed) instance. Never returns null. Returns an instance allocated on the heap! Must call MR_BooleanResultMapper_Destroy() to free it when you're done using it.

MR_BooleanResultMapper_DefaultConstructArray()

MRC_API MR_BooleanResultMapper * MR_BooleanResultMapper_DefaultConstructArray

(

size_t

num_elems

)

Constructs an array of empty (default-constructed) instances, of the specified size. Will never return null. The array must be destroyed using MR_BooleanResultMapper_DestroyArray(). Use MR_BooleanResultMapper_OffsetMutablePtr() and MR_BooleanResultMapper_OffsetPtr() to access the array elements.

MR_BooleanResultMapper_Destroy()

MRC_API void MR_BooleanResultMapper_Destroy

(

const MR_BooleanResultMapper *

_this

)

Destroys a heap-allocated instance of MR_BooleanResultMapper. Does nothing if the pointer is null.

MR_BooleanResultMapper_DestroyArray()

MRC_API void MR_BooleanResultMapper_DestroyArray

(

const MR_BooleanResultMapper *

_this

)

Destroys a heap-allocated array of MR_BooleanResultMapper. Does nothing if the pointer is null.

MR_BooleanResultMapper_filteredOldFaceBitSet()

MRC_API MR_FaceBitSet * MR_BooleanResultMapper_filteredOldFaceBitSet	(	MR_BooleanResultMapper *	_this,
		const MR_FaceBitSet *	oldBS,
		MR_BooleanResultMapper_MapObject	obj )

returns updated oldBS leaving only faces that has corresponding ones in result mesh Generated from a method of class MR::BooleanResultMapper named filteredOldFaceBitSet. Parameter _this can not be null. It is a single object. Parameter oldBS can not be null. It is a single object. Never returns null. Returns an instance allocated on the heap! Must call MR_FaceBitSet_Destroy() to free it when you're done using it.

MR_BooleanResultMapper_Get_maps()

MRC_API const MR_std_array_MR_BooleanResultMapper_Maps_2 * MR_BooleanResultMapper_Get_maps

(

const MR_BooleanResultMapper *

_this

)

Returns a pointer to a member variable of class MR::BooleanResultMapper named maps. Parameter _this can not be null. It is a single object. The returned pointer will never be null. It is non-owning, do NOT destroy it.

MR_BooleanResultMapper_getMaps()

MRC_API const MR_BooleanResultMapper_Maps * MR_BooleanResultMapper_getMaps	(	const MR_BooleanResultMapper *	_this,
		MR_BooleanResultMapper_MapObject	index )

Generated from a method of class MR::BooleanResultMapper named getMaps. Parameter _this can not be null. It is a single object. The returned pointer will never be null. It is non-owning, do NOT destroy it.

MR_BooleanResultMapper_GetMutable_maps()

MRC_API MR_std_array_MR_BooleanResultMapper_Maps_2 * MR_BooleanResultMapper_GetMutable_maps

(

MR_BooleanResultMapper *

_this

)

Returns a mutable pointer to a member variable of class MR::BooleanResultMapper named maps. Parameter _this can not be null. It is a single object. The returned pointer will never be null. It is non-owning, do NOT destroy it.

MR_BooleanResultMapper_map_MR_EdgeBitSet()

MRC_API MR_EdgeBitSet * MR_BooleanResultMapper_map_MR_EdgeBitSet	(	const MR_BooleanResultMapper *	_this,
		const MR_EdgeBitSet *	oldBS,
		MR_BooleanResultMapper_MapObject	obj )

Returns edges bitset of result mesh corresponding input one Generated from a method of class MR::BooleanResultMapper named map. Parameter _this can not be null. It is a single object. Parameter oldBS can not be null. It is a single object. Never returns null. Returns an instance allocated on the heap! Must call MR_EdgeBitSet_Destroy() to free it when you're done using it.

MR_BooleanResultMapper_map_MR_FaceBitSet()

MRC_API MR_FaceBitSet * MR_BooleanResultMapper_map_MR_FaceBitSet	(	const MR_BooleanResultMapper *	_this,
		const MR_FaceBitSet *	oldBS,
		MR_BooleanResultMapper_MapObject	obj )

Returns faces bitset of result mesh corresponding input one Generated from a method of class MR::BooleanResultMapper named map. Parameter _this can not be null. It is a single object. Parameter oldBS can not be null. It is a single object. Never returns null. Returns an instance allocated on the heap! Must call MR_FaceBitSet_Destroy() to free it when you're done using it.

MR_BooleanResultMapper_map_MR_UndirectedEdgeBitSet()

MRC_API MR_UndirectedEdgeBitSet * MR_BooleanResultMapper_map_MR_UndirectedEdgeBitSet	(	const MR_BooleanResultMapper *	_this,
		const MR_UndirectedEdgeBitSet *	oldBS,
		MR_BooleanResultMapper_MapObject	obj )

Returns undirected edges bitset of result mesh corresponding input one Generated from a method of class MR::BooleanResultMapper named map. Parameter _this can not be null. It is a single object. Parameter oldBS can not be null. It is a single object. Never returns null. Returns an instance allocated on the heap! Must call MR_UndirectedEdgeBitSet_Destroy() to free it when you're done using it.

MR_BooleanResultMapper_map_MR_VertBitSet()

MRC_API MR_VertBitSet * MR_BooleanResultMapper_map_MR_VertBitSet	(	const MR_BooleanResultMapper *	_this,
		const MR_VertBitSet *	oldBS,
		MR_BooleanResultMapper_MapObject	obj )

Returns vertices bitset of result mesh corresponding input one Generated from a method of class MR::BooleanResultMapper named map. Parameter _this can not be null. It is a single object. Parameter oldBS can not be null. It is a single object. Never returns null. Returns an instance allocated on the heap! Must call MR_VertBitSet_Destroy() to free it when you're done using it.

MR_BooleanResultMapper_Maps_AssignFromAnother()

MRC_API MR_BooleanResultMapper_Maps * MR_BooleanResultMapper_Maps_AssignFromAnother	(	MR_BooleanResultMapper_Maps *	_this,
		MR_PassBy	_other_pass_by,
		MR_BooleanResultMapper_Maps *	_other )

Generated from a method of class MR::BooleanResultMapper::Maps named operator=. Parameter _this can not be null. It is a single object. The returned pointer will never be null. It is non-owning, do NOT destroy it.

MR_BooleanResultMapper_Maps_ConstructFrom()

MRC_API MR_BooleanResultMapper_Maps * MR_BooleanResultMapper_Maps_ConstructFrom	(	MR_PassBy	cut2origin_pass_by,
		MR_FaceMap *	cut2origin,
		MR_PassBy	cut2newFaces_pass_by,
		MR_FaceMap *	cut2newFaces,
		MR_PassBy	old2newEdges_pass_by,
		MR_WholeEdgeMap *	old2newEdges,
		MR_PassBy	old2newVerts_pass_by,
		MR_VertMap *	old2newVerts,
		bool	identity )

Constructs MR::BooleanResultMapper::Maps elementwise. Never returns null. Returns an instance allocated on the heap! Must call MR_BooleanResultMapper_Maps_Destroy() to free it when you're done using it.

MR_BooleanResultMapper_Maps_ConstructFromAnother()

MRC_API MR_BooleanResultMapper_Maps * MR_BooleanResultMapper_Maps_ConstructFromAnother	(	MR_PassBy	_other_pass_by,
		MR_BooleanResultMapper_Maps *	_other )

Generated from a constructor of class MR::BooleanResultMapper::Maps. Never returns null. Returns an instance allocated on the heap! Must call MR_BooleanResultMapper_Maps_Destroy() to free it when you're done using it.

MR_BooleanResultMapper_Maps_DefaultConstruct()

MRC_API MR_BooleanResultMapper_Maps * MR_BooleanResultMapper_Maps_DefaultConstruct

(

void

)

Constructs an empty (default-constructed) instance. Never returns null. Returns an instance allocated on the heap! Must call MR_BooleanResultMapper_Maps_Destroy() to free it when you're done using it.

MR_BooleanResultMapper_Maps_DefaultConstructArray()

MRC_API MR_BooleanResultMapper_Maps * MR_BooleanResultMapper_Maps_DefaultConstructArray

(

size_t

num_elems

)

Constructs an array of empty (default-constructed) instances, of the specified size. Will never return null. The array must be destroyed using MR_BooleanResultMapper_Maps_DestroyArray(). Use MR_BooleanResultMapper_Maps_OffsetMutablePtr() and MR_BooleanResultMapper_Maps_OffsetPtr() to access the array elements.

MR_BooleanResultMapper_Maps_Destroy()

MRC_API void MR_BooleanResultMapper_Maps_Destroy

(

const MR_BooleanResultMapper_Maps *

_this

)

Destroys a heap-allocated instance of MR_BooleanResultMapper_Maps. Does nothing if the pointer is null.

MR_BooleanResultMapper_Maps_DestroyArray()

MRC_API void MR_BooleanResultMapper_Maps_DestroyArray

(

const MR_BooleanResultMapper_Maps *

_this

)

Destroys a heap-allocated array of MR_BooleanResultMapper_Maps. Does nothing if the pointer is null.

MR_BooleanResultMapper_Maps_Get_cut2newFaces()

MRC_API const MR_FaceMap * MR_BooleanResultMapper_Maps_Get_cut2newFaces

(

const MR_BooleanResultMapper_Maps *

_this

)

"after cut" faces to "after stitch" faces (1-1) Returns a pointer to a member variable of class MR::BooleanResultMapper::Maps named cut2newFaces. Parameter _this can not be null. It is a single object. The returned pointer will never be null. It is non-owning, do NOT destroy it.

MR_BooleanResultMapper_Maps_Get_cut2origin()

MRC_API const MR_FaceMap * MR_BooleanResultMapper_Maps_Get_cut2origin

(

const MR_BooleanResultMapper_Maps *

_this

)

"after cut" faces to "origin" faces this map is not 1-1, but N-1 Returns a pointer to a member variable of class MR::BooleanResultMapper::Maps named cut2origin. Parameter _this can not be null. It is a single object. The returned pointer will never be null. It is non-owning, do NOT destroy it.

MR_BooleanResultMapper_Maps_Get_identity()

MRC_API const bool * MR_BooleanResultMapper_Maps_Get_identity

(

const MR_BooleanResultMapper_Maps *

_this

)

old topology indexes are valid if true Returns a pointer to a member variable of class MR::BooleanResultMapper::Maps named identity. Parameter _this can not be null. It is a single object. The returned pointer will never be null. It is non-owning, do NOT destroy it.

MR_BooleanResultMapper_Maps_Get_old2newEdges()

MRC_API const MR_WholeEdgeMap * MR_BooleanResultMapper_Maps_Get_old2newEdges

(

const MR_BooleanResultMapper_Maps *

_this

)

"origin" edges to "after stitch" edges (1-1) Returns a pointer to a member variable of class MR::BooleanResultMapper::Maps named old2newEdges. Parameter _this can not be null. It is a single object. The returned pointer will never be null. It is non-owning, do NOT destroy it.

MR_BooleanResultMapper_Maps_Get_old2newVerts()

MRC_API const MR_VertMap * MR_BooleanResultMapper_Maps_Get_old2newVerts

(

const MR_BooleanResultMapper_Maps *

_this

)

"origin" vertices to "after stitch" vertices (1-1) Returns a pointer to a member variable of class MR::BooleanResultMapper::Maps named old2newVerts. Parameter _this can not be null. It is a single object. The returned pointer will never be null. It is non-owning, do NOT destroy it.

MR_BooleanResultMapper_Maps_GetMutable_cut2newFaces()

MRC_API MR_FaceMap * MR_BooleanResultMapper_Maps_GetMutable_cut2newFaces

(

MR_BooleanResultMapper_Maps *

_this

)

"after cut" faces to "after stitch" faces (1-1) Returns a mutable pointer to a member variable of class MR::BooleanResultMapper::Maps named cut2newFaces. Parameter _this can not be null. It is a single object. The returned pointer will never be null. It is non-owning, do NOT destroy it.

MR_BooleanResultMapper_Maps_GetMutable_cut2origin()

MRC_API MR_FaceMap * MR_BooleanResultMapper_Maps_GetMutable_cut2origin

(

MR_BooleanResultMapper_Maps *

_this

)

"after cut" faces to "origin" faces this map is not 1-1, but N-1 Returns a mutable pointer to a member variable of class MR::BooleanResultMapper::Maps named cut2origin. Parameter _this can not be null. It is a single object. The returned pointer will never be null. It is non-owning, do NOT destroy it.

MR_BooleanResultMapper_Maps_GetMutable_identity()

MRC_API bool * MR_BooleanResultMapper_Maps_GetMutable_identity

(

MR_BooleanResultMapper_Maps *

_this

)

old topology indexes are valid if true Returns a mutable pointer to a member variable of class MR::BooleanResultMapper::Maps named identity. Parameter _this can not be null. It is a single object. The returned pointer will never be null. It is non-owning, do NOT destroy it.

MR_BooleanResultMapper_Maps_GetMutable_old2newEdges()

MRC_API MR_WholeEdgeMap * MR_BooleanResultMapper_Maps_GetMutable_old2newEdges

(

MR_BooleanResultMapper_Maps *

_this

)

"origin" edges to "after stitch" edges (1-1) Returns a mutable pointer to a member variable of class MR::BooleanResultMapper::Maps named old2newEdges. Parameter _this can not be null. It is a single object. The returned pointer will never be null. It is non-owning, do NOT destroy it.

MR_BooleanResultMapper_Maps_GetMutable_old2newVerts()

MRC_API MR_VertMap * MR_BooleanResultMapper_Maps_GetMutable_old2newVerts

(

MR_BooleanResultMapper_Maps *

_this

)

"origin" vertices to "after stitch" vertices (1-1) Returns a mutable pointer to a member variable of class MR::BooleanResultMapper::Maps named old2newVerts. Parameter _this can not be null. It is a single object. The returned pointer will never be null. It is non-owning, do NOT destroy it.

MR_BooleanResultMapper_Maps_OffsetMutablePtr()

MRC_API MR_BooleanResultMapper_Maps * MR_BooleanResultMapper_Maps_OffsetMutablePtr	(	MR_BooleanResultMapper_Maps *	ptr,
		ptrdiff_t	i )

Offsets a pointer to an array element by i positions (not bytes). Use only if you're certain that the pointer points to an array element.

MR_BooleanResultMapper_Maps_OffsetPtr()

MRC_API const MR_BooleanResultMapper_Maps * MR_BooleanResultMapper_Maps_OffsetPtr	(	const MR_BooleanResultMapper_Maps *	ptr,
		ptrdiff_t	i )

Offsets a pointer to an array element by i positions (not bytes). Use only if you're certain that the pointer points to an array element.

MR_BooleanResultMapper_Maps_Set_cut2newFaces()

MRC_API void MR_BooleanResultMapper_Maps_Set_cut2newFaces	(	MR_BooleanResultMapper_Maps *	_this,
		MR_PassBy	value_pass_by,
		MR_FaceMap *	value )

"after cut" faces to "after stitch" faces (1-1) Modifies a member variable of class MR::BooleanResultMapper::Maps named cut2newFaces. Parameter _this can not be null. It is a single object.

MR_BooleanResultMapper_Maps_Set_cut2origin()

MRC_API void MR_BooleanResultMapper_Maps_Set_cut2origin	(	MR_BooleanResultMapper_Maps *	_this,
		MR_PassBy	value_pass_by,
		MR_FaceMap *	value )

"after cut" faces to "origin" faces this map is not 1-1, but N-1 Modifies a member variable of class MR::BooleanResultMapper::Maps named cut2origin. Parameter _this can not be null. It is a single object.

MR_BooleanResultMapper_Maps_Set_identity()

MRC_API void MR_BooleanResultMapper_Maps_Set_identity	(	MR_BooleanResultMapper_Maps *	_this,
		bool	value )

old topology indexes are valid if true Modifies a member variable of class MR::BooleanResultMapper::Maps named identity. Parameter _this can not be null. It is a single object.

MR_BooleanResultMapper_Maps_Set_old2newEdges()

MRC_API void MR_BooleanResultMapper_Maps_Set_old2newEdges	(	MR_BooleanResultMapper_Maps *	_this,
		MR_PassBy	value_pass_by,
		MR_WholeEdgeMap *	value )

"origin" edges to "after stitch" edges (1-1) Modifies a member variable of class MR::BooleanResultMapper::Maps named old2newEdges. Parameter _this can not be null. It is a single object.

MR_BooleanResultMapper_Maps_Set_old2newVerts()

MRC_API void MR_BooleanResultMapper_Maps_Set_old2newVerts	(	MR_BooleanResultMapper_Maps *	_this,
		MR_PassBy	value_pass_by,
		MR_VertMap *	value )

"origin" vertices to "after stitch" vertices (1-1) Modifies a member variable of class MR::BooleanResultMapper::Maps named old2newVerts. Parameter _this can not be null. It is a single object.

MR_BooleanResultMapper_newFaces()

MRC_API MR_FaceBitSet * MR_BooleanResultMapper_newFaces

(

const MR_BooleanResultMapper *

_this

)

Returns only new faces that are created during boolean operation Generated from a method of class MR::BooleanResultMapper named newFaces. Parameter _this can not be null. It is a single object. Never returns null. Returns an instance allocated on the heap! Must call MR_FaceBitSet_Destroy() to free it when you're done using it.

MR_BooleanResultMapper_OffsetMutablePtr()

MRC_API MR_BooleanResultMapper * MR_BooleanResultMapper_OffsetMutablePtr	(	MR_BooleanResultMapper *	ptr,
		ptrdiff_t	i )

Offsets a pointer to an array element by i positions (not bytes). Use only if you're certain that the pointer points to an array element.

MR_BooleanResultMapper_OffsetPtr()

MRC_API const MR_BooleanResultMapper * MR_BooleanResultMapper_OffsetPtr	(	const MR_BooleanResultMapper *	ptr,
		ptrdiff_t	i )

Offsets a pointer to an array element by i positions (not bytes). Use only if you're certain that the pointer points to an array element.

MR_BooleanResultMapper_Set_maps()

MRC_API void MR_BooleanResultMapper_Set_maps	(	MR_BooleanResultMapper *	_this,
		MR_PassBy	value_pass_by,
		MR_std_array_MR_BooleanResultMapper_Maps_2 *	value )

Modifies a member variable of class MR::BooleanResultMapper named maps. Parameter _this can not be null. It is a single object.

MR_doBooleanOperation()

MRC_API MR_expected_MR_Mesh_std_string * MR_doBooleanOperation	(	MR_Mesh *	meshACut,
		MR_Mesh *	meshBCut,
		const MR_std_vector_std_vector_MR_EdgeId *	cutEdgesA,
		const MR_std_vector_std_vector_MR_EdgeId *	cutEdgesB,
		MR_BooleanOperation	operation,
		const MR_AffineXf3f *	rigidB2A,
		MR_BooleanResultMapper *	mapper,
		const bool *	mergeAllNonIntersectingComponents,
		const MR_BooleanInternalParameters *	intParams )

Perform boolean operation on cut meshes

Returns

mesh in space of meshA or error.

Note

: actually this function is meant to be internal, use "boolean" instead Generated from function MR::doBooleanOperation. Parameter meshACut can not be null. It is a single object. In C++ this parameter takes an rvalue reference: it might invalidate the passed object, but if your pointer is owning, you must still destroy it manually later. Parameter meshBCut can not be null. It is a single object. In C++ this parameter takes an rvalue reference: it might invalidate the passed object, but if your pointer is owning, you must still destroy it manually later. Parameter cutEdgesA can not be null. It is a single object. Parameter cutEdgesB can not be null. It is a single object. Parameter rigidB2A defaults to a null pointer in C++. Parameter mapper defaults to a null pointer in C++. Parameter mergeAllNonIntersectingComponents has a default argument: false, pass a null pointer to use it. Parameter intParams is a single object. Parameter intParams has a default argument: {}, pass a null pointer to use it. Never returns null. Returns an instance allocated on the heap! Must call MR_expected_MR_Mesh_std_string_Destroy() to free it when you're done using it.
